The high-viscosity gel used in the fracturing construction process is generally prepared from vegetable gum (guar gum) or synthetic polymer. Under certain PH conditions, a cross-linking agent is added to form a pickable gel within a suitable time.
Inquiry
Product Description
The high-viscosity gel used in the fracturing construction process is generally prepared from vegetable gum (guar gum) or synthetic polymer. Under certain PH conditions, a cross-linking agent is added to form a pickable gel within a suitable time.
JKN-ZC1 is suitable for cross-linking guar gum and PAM, especially under conditions of high mineralization.
Technical & Engineering Information
JKN-ZC1 is an organic zirconium crosslinking agent. Zirconium compounds (Zr4+) have strong affinity for hydroxyl and carboxyl groups and can form stable chemical bonds with the functional groups (-OH, -COOH) to form high-viscosity gel. Various polyol ligands achieve the purpose of delayed crosslinking by shielding and delaying the release of zirconium ions; and after the introduction of organic ligands, the stability is improved. Due to the formation of multi-nuclear complex ions, the strength of the unit crosslinking point is increased, thereby improving the temperature and shear resistance of the gel.
Technical Indicators
Technical Indicators of JKN-ZC1
Item | Indicator |
Appearance | Transparent Liquid |
Color | Colorless to yellow |
PH | 6-9 |
Specific Gravity | 1.0-1.2 |
Solubility in water | Soluble |
Recommended Treatment
Recommended dosage: 0.2-0.5%;
JKN-ZC1 has delayed cross-linking and is resistant to temperature and shear. The gel can withstand temperatures of 160-180°C(300-350°F).
JKN-ZC1 can also be used for High salinity brine solution.
JKN-ZC1 has strong adaptability, good stability, low dosage and high cross-linking efficiency.
Packing and Storage
JKN-ZC1 be packed in 200L HDPE or 1000L IBC.
Keep it away from extreme conditions such as places near flames or direct sunlight.
Shelf life is 2 years.
